AJ-003-8
Single Jack

SPECIFICATION:
1.Electrical Char.
Insulation Resistance: 500M-Ohm Min.
Contact Resistance: 20milli-Ohm Max.
Rating Current: 1.5A Max.
Rating Voltage: 120V AC
Dielectric Voltage: 1,000 Vrms 60 Sec. Min.

2.Physical char.
Housing: PBT Glass Filled (UL 94V-0)
Color: Black Color
Spring Wire: 0.45mm Dia. Phosphor Bronze
                     Gold Plating Over Nickel
Temperature Range: -40 / +85 Deg C
